TC53A-20M000-CV015B,Fortiming有源晶振,削峰正弦波输出

频率：20MHz

尺寸：5.00mm x 3.20mm

TC53A-20M000-CV015B,Fortiming有源晶振,削峰正弦波输出可显著降低信号传输过程中的干扰,尤其适合FPGA,MCU,射频模块等核心芯片的时钟供给,同时其紧凑封装(兼容行业通用贴片尺寸)与宽电压输入(通常支持3.3V/5V主流供电),能灵活嵌入消费电子,工业自动化,智能硬件等各类小型化设备,凭借内置高精度石英晶体谐振器与优化的有源驱动电路,该晶振在削峰正弦波输出晶振模式下,不仅具备出色的抗振动,抗冲击性能(符合IEC60068-2系列标准),还能有效抑制电源噪声对输出信号的影响,长期工作无频率漂移累积,平均无故障工作时间(MTBF)超50000小时,满足工业级高可靠性需求.

订购热线：0755-27837162

JLXNR-1

TC53A-20M000-CV015B,Fortiming有源晶振,削峰正弦波输出

从硬件设计便捷性来看,TC53A-20M000-CV015B的削峰正弦波输出具备良好的负载驱动能力(最大支持10个TTL负载或5个CMOS负载),无需外部匹配电阻,电容等元器件即可直接驱动负载,大幅简化了时钟电路的设计流程,减少了PCB板上的元器件数量与占用空间.在环境适应性优化上,部分型号支持内置温补功能(TCXO版本),通过温度传感器实时监测环境温度,并动态调整补偿电路参数,可在-40℃~85℃宽温范围内进一步将频率稳定度提升至±5ppm,满足极端温度环境(如户外工业控制器,车载应用晶振电子设备)的使用需求.此外,该晶振还集成了防反接保护(反向电压输入时自动切断电路,避免芯片损坏),过流保护(输出电流超过10mA时触发限流机制)等安全设计,能有效降低设备调试过程中的损坏风险,减少后期维护时的故障排查时间与更换成本,是兼顾高性能,高可靠性与易用性的时序解决方案.

JLX-2

TC53A-20M000-CV015B,Fortiming有源晶振,削峰正弦波输出

Original model 原厂编码	TC53A-20M000-CV015B
Manufacturer 品牌	Fortiming
Part Series 型号	TC53A无线物联网应用
Type 类型	TCXO
Frequency 频率	20M
Output Type 输出方式	削峰正弦波输出
Supply Voltage 电压	3.0V
Frequency Stability 频率稳定性	±1.5 ppm
Operating Temperature 工作温度	-40° / +85°C
Package Size 包装尺寸	5032mm
Package Height 厚度	-
Termination 脚位	4 pads
Package Type 封装类型	4-SMD
Lead Free 无铅	Yes
Mounting Style 安装方式	Surface Mount
Packaging 包装	Tape and Reel
