MX575ABC25M0000,Microchip微芯晶振,7050陶瓷贴片晶振
频率：25.000M
尺寸：7050mm
MX575ABC25M0000,Microchip微芯晶振,7050陶瓷贴片晶振
MX575ABC25M0000是Microchip微芯推出的高稳定性7050晶振封装陶瓷贴片晶振,采用成熟陶瓷谐振技术,标称频率精准锁定25MHz,为电子设备提供稳定时钟信号源.7.0mm×5.0mm的标准7050封装设计,适配自动化贴片工艺,满足高密度PCB布局需求.产品具备低等效串联电阻(ESR)特性,功耗表现优异,兼容工业级宽电压供电范围,广泛适配消费电子,物联网终端等对时钟精度要求严苛的场景,是兼顾性能与成本的高性价比选择.
MX575ABC25M0000,Microchip微芯晶振,7050陶瓷贴片晶振
|
原厂型号 Originalmodel： |
MX575ABC25M0000 |
品牌brand： |
Microchip |
|
Manufacturer品牌 |
Microchip |
OperatingTemperature温度 |
-40+85℃ |
|
Series型号 |
MX57 |
Current-Supply(Max) |
- |
|
Type类型 |
XO |
PackageHeight高度 |
1.5mm |
|
Frequency频率 |
25M |
Termination 脚位 |
|
|
输出方式 Output： |
PackageType 封装类型 |
6-Smd |
|
|
Voltage-Supply电压 |
2.375-3.63V |
Packaging 包装 |
TapeandReel |
|
FrequencyStability频率稳定度 |
|
安装方式 Installation： |
Surfacemount |
|
Size/Dimension尺寸 |
7050mm |
最小包装数MPQ： |
1000 |
MX575ABC25M0000,Microchip微芯晶振,7050陶瓷贴片晶振
