12.94437晶振,丹麦格耶Geyer晶振,KXO-V97T振荡器
频率：30MHz
尺寸：7.0mm x 5.0mm
12.94437晶振,丹麦格耶Geyer晶振,KXO-V97T振荡器,丹麦格耶KXO-V97T振荡器以工业级稳定性为核心亮点,针对12.94437型号晶振进行专项优化,可在高低温波动,机械振动等复杂工业环境下保持稳定输出.产品具备出色的温度适应性,能在较宽温度范围内(如-40℃~85℃)维持频率偏差在极小范围,适配PLC,工业传感器晶振,数控设备等工业场景.同时,格耶严格的生产质控流程,从原材料筛选到成品检测均层层把关,确保每台KXO-V97T振荡器都具备低失效率,长寿命的工业级品质.
订购热线：0755-27837162
12.94437晶振,丹麦格耶Geyer晶振,KXO-V97T振荡器
丹麦格耶KXO-V97T振荡器具备出色的兼容性,可灵活适配不同品牌,不同型号的主控芯片与电路系统,12.94437产品采用标准化接口设计,便于工程师快速集成到现有电路中,无需大幅调整设计方案,降低研发与生产周期.此外,其稳定的频率输出特性,能与各类外设精准配合,保障智能计量设备,工业通信模块等场景的数据处理与信号传输效率.融入低功耗晶振设计理念,能有效降低设备整体能耗,适配便携式工业检测设备,无线传感终端等需电池供电的场景.其紧凑的封装结构可节省PCB板空间,便于在小型化设备中集成,同时无源相关特性(若适用,可根据实际补充)进一步简化电路设计,减少外围元件需求,既降低成本,又提升电路运行的稳定性,为低功耗设备的长时间续航提供有力支持.
12.94437晶振,丹麦格耶Geyer晶振,KXO-V97T振荡器
| 原厂型号 Originalmodel： |
          12.94437
|
品牌brand： |
                     丹麦格耶Geyer
|
| Manufacturer品牌 |
  Geyer晶振
|
OperatingTemperature温度 | -40℃~+85℃ |
| Series型号 |
   KXO-V97T
|
Current-Supply(Max) | - |
| Type类型 | XO | PackageHeight高度 | 1.3mm |
| Frequency频率 |
  30M
|
Termination 脚位 |
 4-pad
|
| 输出方式 Output： | - | PackageType 封装类型 | 4-SMD |
| Voltage-Supply电压 | 3.3V | Packaging 包装 | TapeandReel |
| FrequencyStability频率稳定度 |
      ±100PPm
|
安装方式 Installation： | Surfacemount |
| Size/Dimension尺寸 | 7050mm | 最小包装数MPQ： | 1000 |
12.94437晶振,丹麦格耶Geyer晶振,KXO-V97T振荡器
12.94437晶振,丹麦格耶Geyer晶振,KXO-V97T振荡器
| 12.87000 | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.036/°C² ±10% |
| 12.87001 | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.036/°C² ±10% |
| 12.87002 | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.036/°C² ±10% |
| 12.87034 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 4 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87080 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87081 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87083 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87086 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87090 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87095 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87105 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 10 ppm | -0.042/°C² ±10% |
| 12.87107 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87109 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12 pF | ± 15 ppm | -0.042/°C² ±10% |
| 12.87110 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87111 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87112 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87113 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.042/°C² ±10% |
| 12.87114 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87115 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.042/°C² ±10% |
| 12.87116 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.042/°C² ±10% |
| 12.87118 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87119 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87120 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87121 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.034/°C² ±10% |
| 12.87123 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87126 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87127 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87128 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87129 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87130 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87131 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87132 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87133 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87134 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87135 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87136 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87137 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87138 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.033/°C² ±10% |
| 12.87139 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87143 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87144 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 5.0 ppm | -0.035/°C² ±10% |
| 12.87145 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87146 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87147 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87148 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87149 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87150 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87151 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 30 ppm | -0.035/°C² ±10% |
| 12.87152 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87153 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87155 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.035/°C² ±10% |
| 12.87157 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.035/°C² ±10% |
| 12.87158 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87159 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87160 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87161 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.030/°C² ±10% |
| 12.87163 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87164 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 30 ppm | -0.030/°C² ±10% |
| 12.87165 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87166 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.04/°C² |
