7X54070001,TXC有源晶体振荡器,3.3V压电晶振

当前位置：首页 » 石英晶振 » 7X54070001,TXC有源晶体振荡器,3.3V压电晶振

prevnext

7X54070001,TXC有源晶体振荡器,3.3V压电晶振

频率：54MHz

尺寸：3225mm

7X54070001,TXC有源晶体振荡器,3.3V压电晶振的工作电压与消费电子主流供电电压匹配,无需额外电压转换模块,降低电路复杂度,同时具备优异的频率稳定度,保障蓝牙,WiFi信号传输的稳定性,减少数据丢包现象.

订购热线：0755-27837162

JLX-1

7X54070001,TXC有源晶体振荡器,3.3V压电晶振

7X54070001搭配TXC有源晶体振荡器与3.3V压电晶振,构建工业通信应用晶振控制设备的稳定时钟系统.7X54070001具备精准的频率输出特性,频率偏差控制在±50ppm内,保障工业PLC,传感器数据采集的准确性,TXC有源晶体振荡器采用工业级设计,可在-40℃~105℃宽温环境下稳定工作,抗电磁干扰能力强,适应工厂复杂电磁环境,3.3V压电晶振的低功耗特性显著,静态电流仅3mA,搭配工业设备低功耗供电系统,延长设备持续运行时间,满足工业自动化24小时不间断作业需求.

JLX-2

7X54070001,TXC有源晶体振荡器,3.3V压电晶振

原厂型号 Originalmodel：	7X54070001	品牌brand：	TXC宽温晶振
Manufacturer品牌	TXC	OperatingTemperature温度	-40°C ~ 105°C
Series型号	7X	Current-Supply(Max)	-
Type类型	XO	PackageHeight高度	1.0mm
Frequency频率	54MHz	Termination 脚位	4-pad
输出方式 Output：	CMOS输出	PackageType 封装类型	4-Smd
Voltage-Supply电压	3.3V晶振	Packaging 包装	TapeandReel
FrequencyStability频率稳定度	±50ppm	安装方式 Installation：	Surfacemount
Size/Dimension尺寸	3225mm	最小包装数MPQ：	3000

JLX-3

7X54070001,TXC有源晶体振荡器,3.3V压电晶振

TXC_7XZ_3225 CMOS
