遥遥领先的Harmony Electronics在石英晶体元件的多方面应用

返回列表 来源:金洛鑫 浏览:- 发布日期:2023-09-28 08:58:02【
分享到:

自1976年以来,Harmony Electronics Corp (H.ELE .)一直生产石英晶体频率电子元件,包括用于汽车、消费者和工业的晶体。与日本大真空公司(KDS)的合作帮助H.ELE建立了自己的研究能力。通过在台湾、泰国和中国的生产基地,H.ELE提供具有宽工作温度范围的晶体振荡器和谐振器产品,并专注于小型化趋势。HELE晶体的全球销售团队与全球客户有效沟通。公司履行企业社会责任,旨在为全球社会和客户提供价值。H.ELE是高质量晶体频率元件的全球供应商。

在Harmony Electronics,我们处于在各种行业中利用石英晶体元件的最前沿。我们的产品广泛应用于汽车、医疗、数据通信等领域。在这篇文章中,我们将深入探讨这些应用,特别关注晶体振荡器和晶体谐振器在汽车和医疗领域的应用。

3

汽车电子:用石英晶体元推动创新

在汽车电子领域,石英晶体元件起着至关重要的作用。它们构成了晶体振荡器电路和晶体定时器等系统的主干,是许多汽车电子设备功能不可或缺的组成部分。

石英频率是汽车级晶体的关键因素,具有出色的稳定性和精度。例如,我们的OCXO(恒温晶体振荡器)和TCXO(温度补偿晶体振荡器)产品提供可靠和精确的频率控制,即使在变化的环境条件下。

此外,我们的32.768 kHz晶体通常用于实时车辆时钟,有助于计时和事件记录等功能。我们的石英晶体组件也用于天线服务,确保车辆内部和车辆之间精确和一致的通信。

医疗行业:水晶般透明的未来

在医疗技术领域,石英晶体元件同样至关重要。它们被用于从诊断工具到治疗设备的一系列设备中。

石英晶体频率确保各种医疗设备的可靠运行。这包括心率监视器,其中晶体振荡器有助于保持令人满意的节奏,以及医疗成像机器,这有助于为诊断和治疗生成精确的图像。

此外,石英晶体的压电特性使其在超声波设备中非常有用。在这里,晶体充当电声转换器,将电能转换为声波,声波可以穿透身体,并创建内部结构的图像。

超越汽车和医疗应用

虽然汽车和医疗应用是我们Harmony Electronics关注的重要部分,但我们的石英晶体元件也在其他几个领域得到了应用。例如,在数据通信中,石英晶体组件确保网络设备的平稳运行,实现稳定快速的数据传输。在科学仪器中,它们被用来制造特殊的透镜、窗口和过滤器。


数据通信:连通性的支柱

随着我们对数字时代的深入研究,石英晶体元件在数据通信中的作用变得越来越重要。这些组件不仅是我们设备的组成部分;它们是我们联系的支柱。

晶体振荡器电路是许多数据通信设备(如路由器、调制解调器和交换机)中的关键组件。它的主要功能是产生稳定的频率输出,这对于同步数据传输和接收至关重要。稳定的频率可确保从一台设备发送的数据包到达目的地时不会丢失或损坏。

数据通信中最常用的振荡器之一是温补晶体振荡器(TCXO)。TCXO以其在较宽温度范围内的出色稳定性而闻名,即使在变化的环境条件下也能确保稳定的性能。这使得它成为温度波动较大的室外通信设备的理想选择。

石英晶体在数据通信中的另一个重要应用是网络设备中信号的定时。例如,32.768 kHz晶体经常用于实时时钟中。准确的定时对于协调网络中多台设备的运行、防止数据冲突以及确保数据流顺畅至关重要。

石英晶体频率在无线通信中也起着关键作用。它用于RF电路的设计,帮助确定信号的载波频率。随着无线技术和物联网(IoT)的快速发展,对高质量、可靠的石英晶体元件的需求预计将进一步增长。

总之,石英晶体组件构成了我们这个互联世界的心跳。在Harmony Electronics,我们致力于开发高质量、可靠的石英晶体元件,为数据通信行业及其他行业提供动力。我们的使命是连接世界,一次一个水晶。

原厂编码 制造厂家 型号 频率 负载 频率容差 频率稳定性 工作温度 尺寸
X3S008000BK1H-U HELE晶振 HSX321S 8.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S009000BK1H-U HELE晶振 HSX321S 9.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S010000BK1H-U HELE晶振 HSX321S 10.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S011000BK1H-U HELE晶振 HSX321S 11.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S012000BK1H-U HELE晶振 HSX321S 12.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S013000BK1H-U HELE晶振 HSX321S 13.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S014000BK1H-U HELE晶振 HSX321S 14.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S015000BK1H-U HELE晶振 HSX321S 15.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S016000BK1H-U HELE晶振 HSX321S 16.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S017000BK1H-U HELE晶振 HSX321S 17.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S018000BK1H-U HELE晶振 HSX321S 18.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S019000BK1H-U HELE晶振 HSX321S 19.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S020000BK1H-U HELE晶振 HSX321S 20.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S021000BK1H-U HELE晶振 HSX321S 21.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S022000BK1H-U HELE晶振 HSX321S 22.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S023000BK1H-U HELE晶振 HSX321S 23.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X3S024000BK1H-U HELE晶振 HSX321S 24.000MHZ 20PF ±10PPM ±10PPM -30~85°C 3.2mm×2.5mm
X2C032000BA1HA-U HELE晶振 HSX211S 32MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C012000BA1HA-U HELE晶振 HSX211S 12MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C013000BA1HA-U HELE晶振 HSX211S 13MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C014000BA1HA-U HELE晶振 HSX211S 14MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C015000BA1HA-U HELE晶振 HSX211S 15MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C016000BA1HA-U HELE晶振 HSX211S 16MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C017000BA1HA-U HELE晶振 HSX211S 17MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C018000BA1HA-U HELE晶振 HSX211S 18MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C019000BA1HA-U HELE晶振 HSX211S 19MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C020000BA1HA-U HELE晶振 HSX211S 20MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C021000BA1HA-U HELE晶振 HSX211S 21MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C022000BA1HA-U HELE晶振 HSX211S 22MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C023000BA1HA-U HELE晶振 HSX211S 23MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C024000BA1HA-U HELE晶振 HSX211S 24MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C025000BA1HA-U HELE晶振 HSX211S 25MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C026000BA1HA-U HELE晶振 HSX211S 26MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C027000BA1HA-U HELE晶振 HSX211S 27MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C028000BA1HA-U HELE晶振 HSX211S 28MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C029000BA1HA-U HELE晶振 HSX211S 29MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C030000BA1HA-U HELE晶振 HSX211S 30MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C031000BA1HA-U HELE晶振 HSX211S 31MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C048000BA1HA-U HELE晶振 HSX211S 48MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C033000BA1HA-U HELE晶振 HSX211S 33MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C034000BA1HA-U HELE晶振 HSX211S 34MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C035000BA1HA-U HELE晶振 HSX211S 35MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C036000BA1HA-U HELE晶振 HSX211S 36MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C037000BA1HA-U HELE晶振 HSX211S 37MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C038000BA1HA-U HELE晶振 HSX211S 38MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C039000BA1HA-U HELE晶振 HSX211S 39MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C040000BA1HA-U HELE晶振 HSX211S 40MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C041000BA1HA-U HELE晶振 HSX211S 41MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C042000BA1HA-U HELE晶振 HSX211S 42MHz 10pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2C037400BG1HA-U HELE晶振 HSX211S 37.4MHz 16pF ±10PPM ±20PPM -40~85°C 2.0×1.6mm
X2B02863ADC1H-W HELE晶振 HSX221SA 28.636360MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B010000ADC1H-W HELE晶振 HSX221SA 10MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B011000ADC1H-W HELE晶振 HSX221SA 11MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B012000ADC1H-W HELE晶振 HSX221SA 12MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B013000ADC1H-W HELE晶振 HSX221SA 13MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B014000ADC1H-W HELE晶振 HSX221SA 14MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B015000ADC1H-W HELE晶振 HSX221SA 15MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B016000ADC1H-W HELE晶振 HSX221SA 16MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B017000ADC1H-W HELE晶振 HSX221SA 17MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B018000ADC1H-W HELE晶振 HSX221SA 18MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B019000ADC1H-W HELE晶振 HSX221SA 19MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B020000ADC1H-W HELE晶振 HSX221SA 20MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B021000ADC1H-W HELE晶振 HSX221SA 21MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B022000ADC1H-W HELE晶振 HSX221SA 22MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B023000ADC1H-W HELE晶振 HSX221SA 23MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B024000ADC1H-W HELE晶振 HSX221SA 24MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B025000ADC1H-W HELE晶振 HSX221SA 25MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B026000ADC1H-W HELE晶振 HSX221SA 26MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B027000ADC1H-W HELE晶振 HSX221SA 27MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B028000ADC1H-W HELE晶振 HSX221SA 28MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B029000ADC1H-W HELE晶振 HSX221SA 29MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B030000ADC1H-W HELE晶振 HSX221SA 30MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B031000ADC1H-W HELE晶振 HSX221SA 31MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B032000ADC1H-W HELE晶振 HSX221SA 32MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B033000ADC1H-W HELE晶振 HSX221SA 33MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B034000ADC1H-W HELE晶振 HSX221SA 34MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B035000ADC1H-W HELE晶振 HSX221SA 35MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B036000ADC1H-W HELE晶振 HSX221SA 36MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B037000ADC1H-W HELE晶振 HSX221SA 37MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B038000ADC1H-W HELE晶振 HSX221SA 38MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B039000ADC1H-W HELE晶振 HSX221SA 39MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B040000ADC1H-W HELE晶振 HSX221SA 40MHz 12pF ±20PPM ±20PPM -20~70°C 2.5×2.0mm
X2B038400BA1H-U HELE晶振 HSX221SA 38.4MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B016000BA1H-U HELE晶振 HSX221SA 16MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B017000BA1H-U HELE晶振 HSX221SA 17MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B018000BA1H-U HELE晶振 HSX221SA 18MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B019000BA1H-U HELE晶振 HSX221SA 19MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B020000BA1H-U HELE晶振 HSX221SA 20MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B021000BA1H-U HELE晶振 HSX221SA 21MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B022000BA1H-U HELE晶振 HSX221SA 22MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B023000BA1H-U HELE晶振 HSX221SA 23MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B024000BA1H-U HELE晶振 HSX221SA 24MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B025000BA1H-U HELE晶振 HSX221SA 25MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B026000BA1H-U HELE晶振 HSX221SA 26MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B027000BA1H-U HELE晶振 HSX221SA 27MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B028000BA1H-U HELE晶振 HSX221SA 28MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B029000BA1H-U HELE晶振 HSX221SA 29MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B030000BA1H-U HELE晶振 HSX221SA 30MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B031000BA1H-U HELE晶振 HSX221SA 31MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B032000BA1H-U HELE晶振 HSX221SA 32MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B033000BA1H-U HELE晶振 HSX221SA 33MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B034000BA1H-U HELE晶振 HSX221SA 34MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B035000BA1H-U HELE晶振 HSX221SA 35MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B036000BA1H-U HELE晶振 HSX221SA 36MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B037000BA1H-U HELE晶振 HSX221SA 37MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B038000BA1H-U HELE晶振 HSX221SA 38MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B039000BA1H-U HELE晶振 HSX221SA 39MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B040000BA1H-U HELE晶振 HSX221SA 40MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B041000BA1H-U HELE晶振 HSX221SA 41MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B042000BA1H-U HELE晶振 HSX221SA 42MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B043000BA1H-U HELE晶振 HSX221SA 43MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B044000BA1H-U HELE晶振 HSX221SA 44MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B045000BA1H-U HELE晶振 HSX221SA 45MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
X2B046000BA1H-U HELE晶振 HSX221SA 46MHz 10pF ±10PPM ±10PPM -20~70°C 2.5×2.0mm
